DESCRIPTION

$25 via
Download

Additional information, including earlier Schematic Versions, Errata, Update and Alignment pages, along with a copy of Drakemod 6A.  Also included is never before published data on the Passband Tuner, both electrical and mechanical.
High resolution scans of original manuals for the R-4B and T-4XB plus related models C-4, FS-4 L-4B, MN2000, W-4, ++.
Full color, high resolution photos of the chassis and each PC board (excluding PTO) with each part identified.

Drake B-Line
Service Data

Complete part list showing all resistors, capacitors and semis keyed to full color photos, showing their location on the PC board or chassis.
