PRODUCT

PRICE

DESCRIPTION

$25 via
Download

Additional information, including earlier Schematic Versions, Errata, Update and Alignment pages, along with a copy of Drakemod 6A.  Also included is never before published data on the Passband Tuner, both electrical and mechanical.
Full color, high resolution photos of the chassis and each PC board (excluding PTO) with each part identified.

Drake A-Line
EARLY
Service Data

Complete part list showing all resistors, capacitors and semis keyed to full color photos, showing their location on the PC board or chassis.

Hi resolution scans of original manuals for the R-4A and T-4X plus related models C-4, FS-4, L-4B, MN2000, W-4, ++

$25 via
Download

Drake A-Line
BOTH
Service Data

$40 via
Download

Drake A-Line
LATE
Service Data
