Drake TR-4 Service Data

Additional information, including eight Schematic Versions, Errata, Update and Alignment pages, along with a copy of Drakemod 6A.
High resolution scans of the original manual for the TR-4, plus related models C-4, FS-4, L-4B, MN2000, W-4, ++
Full color, high resolution photos of the chassis and each PC board (excluding PTO) with each part identified.
Complete part list showing all resistors, capacitors and semis keyed to full color photos, showing their location on the PC board or chassis.

TR-4 &
TR-4C
Combined
 Service Data

$50 via
Download

TR-4 CD
